Torquata 1/8in Shank 3 & 4 Flute Solid Carbide 3.175mm Up Cut Spiral CNC Bit

Torquata CNC solid carbide spiral flute router bits are ideal for routing plastics, composite panel and non-ferrous materials. Torquata is your economical entry into quality CNC routing for the enthusiast and professional maker alike.

Available in 3 or 4 flutes, chose the preferred option from the drop down menu

Torquata upcut single flute spiral CNC router bits

The up-cut action of these CNC bits pulls the material fibres up and out of the cut. This makes these Torquata Up Cut bits ideal for when a clean bottom surface finish is required or when getting maximum chip evacuation on deeper profile cuts is important. More efficient chip evacuation means being able to run the bit at an increased feed rate without creating excess heat. Reducing heat prolongs the life of your router bit.

Applications

Torquata CNC straight bits feature a CNC milled one piece body with 92Rc fine industrial grade carbide. These 3 & 4 flute CNC router bits are designed for high feed rate production work such as cutting parts or deep trenching. Increase your productivity with a Torquata up cut CNC router bit when routing hard and soft woods, plywood and composite materials.

Materials

• Wood (MDF, hardwood) – Good
• Wood (Ply & softwoods) – Good
• Plastics (ABS, acrylic, HPDE etc) – Not Suitable

Key features and benefits

• Chips evacuated up out of the cut producing clean bottom edge finishes – great for deep trenching
• High rate of feed possible so great for production work
• Resist heating extending the life of the bit

Who is Torquata

Torquata is your economical entry into quality CNC routing. All Torquata router bits are back by a limited lifetime warranty. Order your Torquata routing bits today.

Product Code	Shank Size	Cutting Flutes	Cutting Direction	Cutting Diameter	Cutting Height	Overall Length
SCU-032-XE-3-F	1/8in	3	Up Cut	3.175mm	22.0mm	52mm
SCU-032-XE-4-F	1/8in	4	Up Cut	3.175mm	22.0mm	52mm
