Torquata 1/4in & 1/2in Shank Triple Flute Solid Carbide Down Cut Spiral CNC Bits

Torquata CNC solid carbide spiral flute router bits are ideal for routing plastics, composite panel and non-ferrous materials. Torquata is your economical entry into quality CNC routing for the enthusiast and professional maker alike.

Available in a range of cutting diameters, choose the preferred option from the drop down menu

Torquata down cut triple flute CNC spiral router bits

The down cut action of these CNC bits cuts from the surface down ensuring that you have a perfectly clean top and face edges. And because they are triple fluted, you can expect the edge finish to be extra perfect. Down cut bits force the chips downward compacting them into the cut causing the bit to recut the same chips. This action can create heat and potential wear on the bit. This triple flute router bit may be run faster than single or double flute bits and will resist heating extending the bits life.

Applications

Torquata CNC spiral bits feature a CNC milled one piece body with 92Rc fine industrial grade carbide. These triple flute CNC router bits are designed to cut perfectly smooth edges whilst resisting heating. They are ideal for through pocket cuts, edge cuts or any situation when a perfect upper edge or face edge is required in hard and soft woods, plywood and composite materials.

Materials

• Aluminium composite materials – excellent
• Wood (MDF, hardwood) – great (top finish only)
• Wood (Ply & softwoods) – great (top finish only)
• Soft metals (Aluminium & Brass) – not suitable
• Plastics (ABS, acrylic, HPDE etc) – not suitable

Key features and benefits

• Cuts super smooth upper & face edges where little or no finishing is required
• Routes material quickly allowing faster feed rates
• Resist heating extending the life of the bit
• Perfect for cutting multi directional materials such as plywood and figured timber

Who is Torquata

Torquata is your economical entry into quality CNC routing. All Torquata router bits are back by a limited lifetime warranty. Order your Torquata routing bits today.

Product Code	Shank Size	Cutting Flutes	Cutting Direction	Cutting Diameter	Cutting Height	Overall Length
SCD-040-Q-3-F	1/4in	Triple	Down Cut	4.0mm	12.7mm	52mm
SCD-064-Q-3-F	1/4in	Triple	Down Cut	6.35mm	19mm	52mm
SCD-064-XQ-3-F	1/4in	Triple	Down Cut	6.35mm	25.4mm	65mm
SCD-095-H-3-F	1/2in	Triple	Down Cut	9.5mm	31.7mm	77mm
SCD-127-H-3-F	1/2in	Triple	Down Cut	12.7mm	31.7mm	77mm
SCD-127-XH-3-F	1/2in	Triple	Down Cut	12.7mm	50.8mm	102mm
