Sherwood Triton Pre-Drilled Router Mounting Plate

Sherwood offers Australia’s most comprehensive range of router tables, routing equipment and accessories suitable for all types of wood and composite routing applications. Sherwood routing products are the perfect choice for new woodworkers, enthusiasts and professional woodworkers alike.

Please Note: The height adjustment winder shown in photos comes with your Triton router and is not included with this plate.

Using a router in your woodworking is one of the smartest things you can do. Routers and routing tables are compact and versatile, allowing you to complete a huge range of tasks including edge machining, joinery, trenching, decorative routing and pattern/template routing. Routing equipment is simple to set up, safe to use and easy to maintain.

Routing equipment is useful for woodworkers of all skill levels. Once you have learned how your router works and have developed an understanding of the router’s broader potential, your router will become the go-to piece of equipment in your shop. No workshop, whether beginner, enthusiast or professional, should be without a router or router table.

Sherwood PRE-DRILLED mounting plates for the Triton router

The Triton TRA-001 Router is perfect for use in a Sherwood router table. This router’s key feature is the above table height winding mechanism. This allows you to wind the router chuck up above the surface of the router plate for easy, single spanner bit changes.

The Sherwood RTAMP-5 Aluminium Mounting Plate is available pre-drilled for the Triton router. Installation is easy. Simply remove the black plastic router base plate and fix the router to the Sherwood mounting plate. The height winding arm access hole is pre-drilled and marked with rise and fall directions.

Sherwood aluminium mounting plates

Sherwood aluminium router mounting plates are CNC-machined from 6mm-thick aluminium plate. Each plate is checked for flatness and then anodized in Sherwood orange. Sherwood aluminium mounting plates are precisely made and very durable.

Easy leveling

Sherwood mounting plates are easy to set level. Each plate features six adjustable grub screws installed along the outer edges of the mount plate. These ensure a perfectly level fit upon the lip of the router table underneath it.

What size are these plates?

The Sherwood aluminium mounting plate pre-drilled for Triton have moved to the North American industry-standard size of 298 x 235mm with a corner radius of 16mm.

The centre hole is 92.2mm diameter and includes one phenolic twist-lock insert ring with an aperture of 38.1mm. The insert ring spanner comes standard with the mounting plate. Also included is starter pin and two predrilled holes to mount it either side of the bit.

Other Options

The Sherwood aluminium mounting plate pre-drilled for Triton is compatible with other brands of router tables including Kreg, Incra and JessEm.

5-Year warranty

All Sherwood products feature a standard 5-Year limited warranty. No other routing product in its class is more supported than the Sherwood RTAMP-5.

Predrilled for the Triton TRA-001 Router

The Sherwood RTAMP-5 anodized aluminium mounting plate is designed and predrilled for the Triton TRA-001 Router. This means your new Triton router will fix easily and neatly onto the plate. No time will be is wasted in getting to work.

Above table operation

The Sherwood RTAMP-5 mounting plate facilitates easy above-table operation. Use the height adjustment winder to adjust the depth of cut or change the bit. At no time will you find yourself on your hands and knees.

Blissful routing

With your Triton router installed, you now have a most efficient routing ensemble. If you need to do some regular cleaning or maintenance just pop the router and plate out and get cleaning.

Precise and durable

Sherwood aluminium router mounting plates are CNC-machined from 6mm-thick aluminium plate. Each plate is checked for flatness and then anodized in Sherwood orange. Sherwood aluminium mounting plates are precisely made and very durable.

Easy levelling

Sherwood mounting plates are easy to set level. Each plate features six adjustable grub screws installed along the outer edges of the mounting plate. These ensure a perfectly level fit upon the lip of the router table underneath it.

5 Year Warranty

All Sherwood products feature a standard 5-Year limited warranty. No other routing product in its class is more supported than the Sherwood RTAMP-5.
